Products
 |
Description:
Technical Parameter
|
Fiber Count (F) |
Cable Diameter (mm) |
Cable Weight (kgs) |
Tensile Strength (N) | Crush Strength (N) | Min. Bending Radius |
Temperature Range (℃) |
|||
| Long term | Short Term | Long term | Short Term | Long term | Short Term | ||||
| 2~32 | 5.5x10.0 | 215 | 1000 | 3000 | 1000 | 3000 | 10D | 20D | -40~+60 |
| 32~36 | 5.5x10.0 | 238 | 1000 | 3000 | 1000 | 3000 | 10D | 20D | -40~+60 |
| 38~60 | 5.5x10.0 | 242 | 1000 | 3000 | 1000 | 3000 | 10D | 20D | -40~+60 |
| 62~72 | 7.0x12.0 | 273 | 1000 | 3000 | 1000 | 3000 | 10D | 20D | -40~+60 |
| 74~96 | 7.0x12.0 | 302 | 1000 | 3000 | 1000 | 3000 | 10D | 20D | -40~+60 |
| 98~120 | 7.0x12.0 | 338 | 1000 | 3000 | 1000 | 3000 | 10D | 20D | -40~+60 |
| 120~144 | 7.0x14.0 | 374 | 1000 | 3000 | 1000 | 3000 | 10D | 20D | -40~+60 |
| Cable Type | Drum Length(KM) | Drum/Carton size (cm) | Gross weight/CTN (kgs) | KMs/20ft |
| GYTC8S 2~32 | 2 | 100*100*76 | 450 | 72 |
| GYTC8S 32~36 | 2 | 100*100*76 | 500 | 72 |
| GYTC8S 38~60 | 2 | 100*100*76 | 500 | 72 |
| GYTC8S 62~72 | 2 | 100*100*76 | 580 | 72 |
| GYTC8S 74~96 | 2 | 100*100*76 | 650 | 72 |
| GYTC8S 98~120 | 2 | 100*100*76 | 700 | 72 |
| GYTC8S 120~144 | 2 | 100*100*76 | 780 | 72 |
